Engineered to withstand static pressures of up to 15000 psi (1034 bar), the Rosemount 3051S High Static DP Transmitter incorporates the compact, SuperModule™ design for harsh production conditions. A no-equal solution, this transmitter provides differential pressure and temperature measurements and utilizes the Rosemount Coplanar™ technology for reduced installation weight. This transmitter is designed with a coned and threaded direct connection to withstand high static pressure conditions.

Rangedown

Up to 150:1

Communication Protocol

4-20 mA HART, WirelessHART®, FOUNDATION™ Fieldbus

Measurement Range

Up to 150 psi (10.34 bar) Differential with maximum working pressure up to 15,000 psi (1034 bar)

Process Wetted Material

Alloy C-276

Diagnostics

Basic Diagnostics, Loop Integrity, Process Intelligence, Plugged Impulse Line

Certifications/Approvals

SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE, hazardous location, see full specs for complete list of certifications
